Informazioni di Base.
range di concentrazione
0.1mg/l-100mg/l.
angolo di dispersione
90
camera campione
10mm*10mm, 4ml
Pacchetto di Trasporto
Standard Export Wooden Case
Specifiche
61X23X32cm / 13kgs
Marchio
NKT
Origine
Shandong, Jinan
Capacità di Produzione
25/PCS/Month
Descrizione del Prodotto
Scope Of Application
NKT-N9 nano laser particle sizer is widely used for particle characterization of organic or inorganic nanoparticles, emulsions, polymers, micelles, viral antibodies and proteins, and detection and analysis of sample system stability and particle aggregation tendency.
NKT-N9 nano laser particle sizer is widely used for particle characterization of organic or inorganic nanoparticles, emulsions, polymers, micelles, viral antibodies and proteins, and detection and analysis of sample system stability and particle aggregation tendency.
1.Advanced testing principle: The instrument adopts dynamic light scattering principle and photon correlation spectroscopy technology. The particle size is determined according to the Brownian motion speed of particles in liquid. The Brownian motion speed of small particles is fast, and that of large particles is slow. When a laser beam is irradiated on a moving particle, the
scattered light from a certain angle (the instrument uses 90 degrees) changes dynamically with time. The speed of the change is related to the Brownian motion speed of the particle in the liquid. The dynamic scattering spectra are analyzed by photon correlation spectroscopy, and the relevant calculation is carried out according to Stokes-Einst. Ein equation was used to calculate the particle size.
2.High Sensitivity and Signal-to-Noise Ratio (SNR): A HAMAMATSU professional high-performance photo multiplier tube (PMT) with low dark count and high sensitivity is used as detector, which has high sensitivity and SNR to photostatic signal, thus ensuring high accuracy and high resolution of test results.
3.Super computational function: Using PCS technology to measure the size of nano particles, we must be able to distinguish the fluctuation of nanosecond signal. The core component of the instrument is a high-speed photon correlate developed by ASIC. It has the ability of recognizing 6ns with high resolution and high signal processing speed. It can collect photons quickly and real-time and calculate the correlation operation, which lays the foundation for testing accuracy.
4.Stable optical system: The photon correlation spectrum detection system is composed of high-power semiconductor laser and optical fiber controlled by constant temperature, which not only has small size, but also has strong anti-interference ability and stability, and ensures the repeat-ability and stability of the test results.
5.High precision temperature control system: the precision of sample pool temperature control system and laser temperature control system is as high as (+0.1 C), which makes the measured sample and laser light source in a constant temperature state throughout the testing process, avoids the influence of temperature change on the testing results, and ensures the accuracy and repeatably of the testing;
6.High precision temperature control system: the precision of sample pool temperature control system and laser temperature control system is as high as (+0.1 C), which makes the measured sample and laser light source in a constant temperature state throughout the testing process, avoids the influence of temperature change on the testing results, and ensures the accuracy and repeatably of the testing;
7.Super-powerful analysis software: The inversion algorithm in the analysis software adopts the cumulative method recommended by international standards, as well as the commonly used non-negative least squares (NNLS) and Contin algorithms. The test results are in good agreement with the international authoritative products of the same kind.
8.New heat dissipation system: New N9 has a dual-flow design. The hot air is directly discharged from the instrument shell. The multiplier tube, laser, correlate and other important components are no longer affected by the hot air. The measured data are more accurate and stable, and the service life of these important components is greatly prolonged.
9. Automatic induction door: The new N9 is equipped with automatic opening and closing function of the coloration door. When the hand is close to the instrument, the sliding door will open automatically to facilitate the tester to take the coloration dish. When the hand is away from the instrument, the sliding door will close automatically
| Model: | NKT-N9 |
| Execution standard: | GB/T 29022-2012/ISO 22412:2008 |
| Measurement range: | 1-10000nm(related with the samples) |
| Concentration range: | 0.1mg/L-100mg/L |
| Accuracy error: | <1%(Average Particle Size of National Standard Samples) |
| Repeatably error | <1%(Average Particle Size of National Standard Samples) |
| Laser type: | Fiber-optical semi-conductor laser,λ= 532nm |
| Detector: | Photo-multiplier tube(PMT) |
| Scattering angle: | 90° |
| Sample chamber: | 10mm*10mm , 4ml(Temperature-controlled protection) |
| Temperature range: | 5-90ºC(±0.1ºC) |
| Test speed: | <1Min/times(Dispersion time without sample) |
| Main parameters of digital correlator | Physical Channel:512,Equivalent channel:10000,Baseline channel:8, Sampling and Delay Time:1us~200us( Dynamically adjustable), Minimum resolution:6ns |
Jinan Boni Technology Co., Ltd. is a high-tech enterprise engaged in the R&D, production, sales and service of various laboratory instruments and laser instruments and equipment. The company has been highly valued by leaders at provincial, municipal and district levels, and has been listed as a national high-tech enterprise, a software enterprise in Shandong Province and a provincial particle size and shape analysis instrument technology research center,It has profound theoretical research foundation of laser and image particle size distribution measurement and excellent technical innovation ability, has obtained many patents and rich scientific research achievements, and its technical performance and quality have reached the international advanced level.
